Optimal Fusion of Multiresolution Information for Soft Sensor Development, Process Monitoring and Model-Based Estimation



Acronym: MR2BEST

Reference: PTDC/QEQ-EPS/1323/2014

Funding: FCT, PT2020, FEDER

Duration: 15/06/2016 to 15/12/2019

Principal Investigator: Marco S. Reis



Project overview



Process Industries are generating data with a variety of structures that are not handled properly by current approaches for process monitoring, control and optimization. In particular, current methodologies rely heavily on the availability of data at a single resolution and, most often, also at a single acquisition rate. In short terms, resolution is a measure of the degree of localization of the information about a given quantity, over a domain of the relevant independent variables (time or space). For instance, some variables represent instantaneous values from the process (i.e., averages over a very short period of time), while others consist of averages over several minutes, hours, or even days; still others can be measurements representative from a lot produced during the last hour, or from raw-material being fed to the process sometimes during more than 20 days (such as wood ships in the pulp & paper industry). These variables carry information with different time localizations, i.e., at distinct resolutions in time. However, the common tacit assumption is that all process data are available at the same resolution, usually with high localization in the time domain around the sampling instants (which should, furthermore, be equally spaced). Analyzing modern process databases, one can easily verify that this assumption is frequently not met, meaning that these databases present, in general, a multiresolution data structure. However, to the best of our present knowledge, there are no solutions available for handling multiresolution data, even for the critical low level tasks, such as process monitoring and control, the only exception being a methodology proposed by the PI in 2006 (Reis & Saraiva, 2006c). As referred in this publication, even the so called multiscale approaches assume the presence of data at a single resolution, a fact that is often overlooked. A similar situation is found in the strategic higher level task of process optimization. Therefore, in this project, we set the goal of developing the conceptual background and theory for multiresolution and multirate approaches in the context of the following process systems engineering (PSE) activities: soft sensors for dynamic stationary (continuous) and non-stationary (batch) processes (project task 1), process monitoring for non-stationary (batch) systems (project task 2) and, finally, mechanistic modelling of processes with multiresolution processing units and the development of suitable optimal estimation tools (project task 3).
